What is the minimum Docker resource requirement for Keycloak in production?

Keycloak requires minimum 2 GB RAM and 2 CPU cores for production. Set container memory limits with deploy.resources.limits.memory: 2G. The JVM default uses MaxRAMPercentage=70 for heap allocation, leaving 30% for non-heap (Metaspace, threads, native memory). For PostgreSQL, allocate minimum 1 GB RAM with shared_buffers set to 25% of container memory.

How do I configure Keycloak behind Nginx or Traefik with Docker Compose?

Set KC_HTTP_ENABLED=true and KC_PROXY_HEADERS=xforwarded on the Keycloak container. Configure your reverse proxy (Nginx, Traefik, or Caddy) to forward X-Forwarded-For, X-Forwarded-Proto, and X-Forwarded-Host headers. Set KC_HOSTNAME to your full public URL (e.g., https://auth.example.com). The old KC_PROXY setting was removed in Keycloak 26 — use KC_PROXY_HEADERS instead.

How do I set up Keycloak clustering with Docker Compose?

Keycloak 26 uses JDBC_PING2 by default for cluster node discovery via the shared PostgreSQL database — no multicast or external discovery service needed. Set KC_CACHE=ispn and KC_CACHE_STACK=jdbc-ping. Ensure all Keycloak containers share a Docker network with ports 7800 (data) and 57800 (failure detection) accessible. Use a load balancer with sticky sessions on the AUTH_SESSION_ID cookie.

Why does Keycloak fail to start with "Failed to initialize Liquibase"?

This error occurs when Keycloak starts before PostgreSQL is ready. Fix it by adding a health check to the PostgreSQL service (pg_isready -U keycloak -d keycloak) and using depends_on with condition: service_healthy in the Keycloak service definition. Set start_period: 30s on the PostgreSQL health check to allow initialization time.

Keycloak Docker Compose Production: Complete Deployment Guide for 2026

Running Keycloak in Docker for development is straightforward. Running it in production requires careful configuration of database pooling, reverse proxy headers, JVM tuning, health checks, and security hardening. This guide provides copy-paste Docker Compose configurations for Keycloak 26.x that are production-ready.

Clone the companion repo: All configurations from this guide are available as a ready-to-run project at IAMDevBox/keycloak-docker-production. Clone it, copy .env.example to .env, set your passwords, and run docker compose up -d.

Single-Node Production Setup

This is the recommended starting point. A single Keycloak instance with PostgreSQL handles thousands of concurrent users.

Docker Compose

services:
  postgres:
    image: postgres:16-alpine
    container_name: keycloak-postgres
    restart: unless-stopped
    volumes:
      - pgdata:/var/lib/postgresql/data
    environment:
      POSTGRES_DB: keycloak
      POSTGRES_USER: keycloak
      POSTGRES_PASSWORD: ${DB_PASSWORD}
    networks:
      - internal
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U keycloak -d keycloak"]
      interval: 10s
      timeout: 5s
      retries: 5
      start_period: 30s
    deploy:
      resources:
        limits:
          memory: 1G
          cpus: "1.0"

  keycloak:
    image: quay.io/keycloak/keycloak:26.1
    container_name: keycloak
    command: start --optimized
    restart: unless-stopped
    depends_on:
      postgres:
        condition: service_healthy
    environment:
      # Database
      KC_DB: postgres
      KC_DB_URL: jdbc:postgresql://postgres:5432/keycloak
      KC_DB_USERNAME: keycloak
      KC_DB_PASSWORD: ${DB_PASSWORD}
      KC_DB_POOL_INITIAL_SIZE: 25
      KC_DB_POOL_MIN_SIZE: 25
      KC_DB_POOL_MAX_SIZE: 25
      # Hostname (TLS terminates at reverse proxy)
      KC_HOSTNAME: https://auth.example.com
      KC_HTTP_ENABLED: "true"
      KC_PROXY_HEADERS: xforwarded
      # Observability
      KC_HEALTH_ENABLED: "true"
      KC_METRICS_ENABLED: "true"
      # Admin bootstrap (first run only)
      KC_BOOTSTRAP_ADMIN_USERNAME: admin
      KC_BOOTSTRAP_ADMIN_PASSWORD: ${ADMIN_PASSWORD}
      # Single-node cache
      KC_CACHE: local
      # Logging
      KC_LOG_LEVEL: info
      KC_LOG_CONSOLE_OUTPUT: json
      # JVM
      JAVA_OPTS_KC_HEAP: >-
        -XX:MaxRAMPercentage=70
        -XX:InitialRAMPercentage=50
        -XX:MaxHeapFreeRatio=30
    ports:
      - "8080:8080"
    networks:
      - frontend
      - internal
    healthcheck:
      test: ["CMD-SHELL", "exec 3<>/dev/tcp/localhost/9000 && echo -e 'GET /health/ready HTTP/1.1\\r\\nHost: localhost\\r\\nConnection: close\\r\\n\\r\\n' >&3 && cat <&3 | grep -q '\"status\": \"UP\"'"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 60s
    deploy:
      resources:
        limits:
          memory: 2G
          cpus: "2.0"
        reservations:
          memory: 1G

volumes:
  pgdata:

networks:
  frontend:
    driver: bridge
  internal:
    driver: bridge
    internal: true

Environment File

Create a .env file (gitignored) alongside your docker-compose.yml:

DB_PASSWORD=change-this-to-a-strong-password
ADMIN_PASSWORD=change-this-to-a-strong-password

Key Configuration Decisions

Database connection pool: The Keycloak docs recommend setting initial, min, and max pool sizes to the same value. This avoids the overhead of creating new connections under load. 25 connections handles most single-node deployments.

KC_CACHE: local: Disables distributed Infinispan caching. For a single node, this eliminates unnecessary cluster discovery overhead.

KC_BOOTSTRAP_ADMIN_USERNAME: Replaces the deprecated KEYCLOAK_ADMIN in Keycloak 26.x. The admin user is created only on first boot — these variables are ignored on subsequent starts.

Health check on port 9000: Keycloak’s management interface runs on port 9000 (separate from the application port 8080). Health endpoints (/health/ready, /health/live) and metrics (/metrics) are served here. Never expose port 9000 publicly.

Network isolation: PostgreSQL sits on an internal network with no external access. Keycloak bridges both frontend (for client traffic) and internal (for database).

Optimized Build for Faster Startup

The stock Keycloak image runs a build phase on every container start, adding 15-30 seconds to startup. Use a multi-stage Dockerfile to pre-build:

FROM quay.io/keycloak/keycloak:26.1 AS builder

ENV KC_DB=postgres
ENV KC_HEALTH_ENABLED=true
ENV KC_METRICS_ENABLED=true
ENV KC_CACHE=ispn

RUN /opt/keycloak/bin/kc.sh build

FROM quay.io/keycloak/keycloak:26.1

COPY --from=builder /opt/keycloak/ /opt/keycloak/

ENTRYPOINT ["/opt/keycloak/bin/kc.sh"]
CMD ["start", "--optimized"]

Replace image: quay.io/keycloak/keycloak:26.1 in your Compose file with:

keycloak:
  build: .
  command: start --optimized

Startup drops from ~30 seconds to under 10 seconds.

Reverse Proxy Configuration

Keycloak in production runs behind a reverse proxy that terminates TLS. Three options:

Nginx

upstream keycloak {
    server keycloak:8080;
}

server {
    listen 443 ssl http2;
    server_name auth.example.com;

    ssl_certificate     /etc/nginx/ssl/fullchain.pem;
    ssl_certificate_key /etc/nginx/ssl/privkey.pem;
    ssl_protocols       TLSv1.2 TLSv1.3;

    # OIDC/SAML endpoints
    location /realms/ {
        proxy_pass http://keycloak;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-Forwarded-Host $host;
        proxy_set_header X-Forwarded-Port $server_port;
        proxy_buffer_size 128k;
        proxy_buffers 4 256k;
        proxy_busy_buffers_size 256k;
    }

    # Static resources (cache aggressively)
    location /resources/ {
        proxy_pass http://keycloak;
        proxy_set_header Host $host;
        expires 1y;
        add_header Cache-Control "public, immutable";
    }

    # OIDC discovery
    location /.well-known/ {
        proxy_pass http://keycloak;
        proxy_set_header Host $host;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Admin console — restrict to internal IPs
    location /admin/ {
        allow 10.0.0.0/8;
        allow 172.16.0.0/12;
        allow 192.168.0.0/16;
        deny all;
        proxy_pass http://keycloak;
        proxy_set_header Host $host;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Block management endpoints
    location /health { deny all; }
    location /metrics { deny all; }
}

Key points:

Only expose /realms/, /resources/, and /.well-known/ publicly
Restrict /admin/ to internal IPs
Never proxy port 9000 (management interface)
Large proxy_buffer_size prevents issues with SAML responses

Traefik (Docker Labels)

keycloak:
  labels:
    - "traefik.enable=true"
    - "traefik.http.routers.keycloak.rule=Host(`auth.example.com`)"
    - "traefik.http.routers.keycloak.entrypoints=websecure"
    - "traefik.http.routers.keycloak.tls.certresolver=letsencrypt"
    - "traefik.http.services.keycloak.loadbalancer.server.port=8080"
    - "traefik.http.services.keycloak.loadbalancer.sticky.cookie=true"
    - "traefik.http.services.keycloak.loadbalancer.sticky.cookie.name=AUTH_SESSION_ID"

Caddy (Automatic TLS)

Caddy automatically provisions Let’s Encrypt TLS certificates — zero manual certificate management.

PostgreSQL Tuning

Default PostgreSQL settings are conservative. Tune for Keycloak’s workload pattern (many small CRUD queries):

postgres:
  image: postgres:16-alpine
  command:
    - "postgres"
    - "-c"
    - "shared_buffers=256MB"
    - "-c"
    - "effective_cache_size=768MB"
    - "-c"
    - "work_mem=4MB"
    - "-c"
    - "maintenance_work_mem=64MB"
    - "-c"
    - "max_connections=50"
    - "-c"
    - "random_page_cost=1.1"
    - "-c"
    - "effective_io_concurrency=200"
    - "-c"
    - "log_min_duration_statement=500"

Sizing rules:

shared_buffers: 25% of container memory (256 MB for a 1 GB container)
effective_cache_size: 75% of container memory
work_mem: 4 MB is sufficient — Keycloak runs simple queries, not complex joins
max_connections: Must be >= Keycloak pool size + monitoring/admin overhead. For single-node with pool size 25, set to 50

Automated Backups

Add a backup sidecar to your Compose file:

backup:
  image: postgres:16-alpine
  entrypoint: /bin/sh
  command: >
    -c 'while true; do
      pg_dump -h postgres -U keycloak -Fc keycloak > /backups/keycloak_$$(date +%Y%m%d_%H%M).dump;
      find /backups -name "keycloak_*.dump" -mtime +7 -delete;
      sleep 86400;
    done'
  environment:
    PGPASSWORD: ${DB_PASSWORD}
  volumes:
    - ./backups:/backups
  networks:
    - internal
  depends_on:
    postgres:
      condition: service_healthy

This creates daily backups and retains 7 days of history.

Multi-Node Clustering

For high availability, run multiple Keycloak instances behind a load balancer. Keycloak 26.x uses JDBC_PING2 by default — nodes discover each other through the shared PostgreSQL database. No multicast or external discovery service required.

Clustered Docker Compose

services:
  postgres:
    image: postgres:16-alpine
    restart: unless-stopped
    volumes:
      - pgdata:/var/lib/postgresql/data
    environment:
      POSTGRES_DB: keycloak
      POSTGRES_USER: keycloak
      POSTGRES_PASSWORD: ${DB_PASSWORD}
    command:
      - "postgres"
      - "-c"
      - "shared_buffers=256MB"
      - "-c"
      - "max_connections=80"
    networks:
      - internal
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U keycloak -d keycloak"]
      interval: 10s
      timeout: 5s
      retries: 5
      start_period: 30s

  keycloak-1:
    image: quay.io/keycloak/keycloak:26.1
    command: start --optimized
    restart: unless-stopped
    depends_on:
      postgres:
        condition: service_healthy
    environment:
      KC_DB: postgres
      KC_DB_URL: jdbc:postgresql://postgres:5432/keycloak
      KC_DB_USERNAME: keycloak
      KC_DB_PASSWORD: ${DB_PASSWORD}
      KC_DB_POOL_INITIAL_SIZE: 20
      KC_DB_POOL_MIN_SIZE: 20
      KC_DB_POOL_MAX_SIZE: 20
      KC_HOSTNAME: https://auth.example.com
      KC_HTTP_ENABLED: "true"
      KC_PROXY_HEADERS: xforwarded
      KC_HEALTH_ENABLED: "true"
      KC_METRICS_ENABLED: "true"
      KC_BOOTSTRAP_ADMIN_USERNAME: admin
      KC_BOOTSTRAP_ADMIN_PASSWORD: ${ADMIN_PASSWORD}
      KC_CACHE: ispn
      KC_CACHE_STACK: jdbc-ping
      KC_LOG_LEVEL: info
      KC_LOG_CONSOLE_OUTPUT: json
      JAVA_OPTS_APPEND: "-Djava.net.preferIPv4Stack=true"
    networks:
      - frontend
      - internal
    healthcheck:
      test: ["CMD-SHELL", "exec 3<>/dev/tcp/localhost/9000 && echo -e 'GET /health/ready HTTP/1.1\\r\\nHost: localhost\\r\\nConnection: close\\r\\n\\r\\n' >&3 && cat <&3 | grep -q '\"status\": \"UP\"'"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 90s

  keycloak-2:
    image: quay.io/keycloak/keycloak:26.1
    command: start --optimized
    restart: unless-stopped
    depends_on:
      postgres:
        condition: service_healthy
      keycloak-1:
        condition: service_healthy
    environment:
      KC_DB: postgres
      KC_DB_URL: jdbc:postgresql://postgres:5432/keycloak
      KC_DB_USERNAME: keycloak
      KC_DB_PASSWORD: ${DB_PASSWORD}
      KC_DB_POOL_INITIAL_SIZE: 20
      KC_DB_POOL_MIN_SIZE: 20
      KC_DB_POOL_MAX_SIZE: 20
      KC_HOSTNAME: https://auth.example.com
      KC_HTTP_ENABLED: "true"
      KC_PROXY_HEADERS: xforwarded
      KC_HEALTH_ENABLED: "true"
      KC_METRICS_ENABLED: "true"
      KC_CACHE: ispn
      KC_CACHE_STACK: jdbc-ping
      KC_LOG_LEVEL: info
      KC_LOG_CONSOLE_OUTPUT: json
      JAVA_OPTS_APPEND: "-Djava.net.preferIPv4Stack=true"
    networks:
      - frontend
      - internal
    healthcheck:
      test: ["CMD-SHELL", "exec 3<>/dev/tcp/localhost/9000 && echo -e 'GET /health/ready HTTP/1.1\\r\\nHost: localhost\\r\\nConnection: close\\r\\n\\r\\n' >&3 && cat <&3 | grep -q '\"status\": \"UP\"'"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 90s

  nginx:
    image: nginx:alpine
    ports:
      - "443:443"
    volumes:
      - ./nginx.conf:/etc/nginx/nginx.conf:ro
      - ./ssl:/etc/nginx/ssl:ro
    depends_on:
      keycloak-1:
        condition: service_healthy
      keycloak-2:
        condition: service_healthy
    networks:
      - frontend

volumes:
  pgdata:

networks:
  frontend:
  internal:
    internal: true

Clustering Key Points

JDBC_PING2 uses the shared database for node discovery. Nodes register themselves in a JGROUPSPING table. No multicast, no external etcd/consul, no cloud-specific discovery.

Sticky sessions are required. The AUTH_SESSION_ID cookie ensures a user’s authentication flow stays on the same node. Without sticky sessions, multi-step login flows will fail. Configure in Nginx:

upstream keycloak_cluster {
    ip_hash;
    server keycloak-1:8080;
    server keycloak-2:8080;
}

Inter-node communication uses ports 7800 (data) and 57800 (failure detection). mTLS between nodes is enabled by default in Keycloak 26.x with auto-generated certificates.

Verify cluster formation:

# Check for cluster join message
docker compose logs keycloak-1 | grep "ISPN000094"

# Check cluster size via metrics
curl -s http://localhost:9000/metrics | grep vendor_cluster_size

Security Hardening

Disable Unused Features

# Add to Keycloak environment
KC_FEATURES_DISABLED: impersonation,kerberos,device-flow,ciba

Disable features you don’t use to reduce attack surface. Common candidates: impersonation (admin impersonating users), device-flow (IoT), ciba (client-initiated backchannel auth).

Separate Admin Hostname

KC_HOSTNAME: https://auth.example.com
KC_HOSTNAME_ADMIN: https://admin.internal.example.com

Serve the admin console on a separate internal hostname, inaccessible from the public internet.

Credential Management

Keycloak does not support Docker secrets _FILE pattern natively. Options from most to least secure:

PKCS12 Keystore (Keycloak-native):

keytool -importpass -alias kc.db-password -keystore conf/keystore.p12 \
  -storepass keystorepass -storetype PKCS12

.env file (simplest, restrict file permissions to 600):

chmod 600 .env

Docker Swarm secrets (via custom entrypoint reading /run/secrets/)

Load Shedding

Prevent cascade failures under extreme load:

KC_HTTP_MAX_QUEUED_REQUESTS: 1000

Requests exceeding the queue receive an immediate 503. At ~200 requests/second throughput, a queue of 1000 means ~5 second maximum wait.

Monitoring

Prometheus Integration

Enable metrics and health endpoints:

KC_HEALTH_ENABLED: "true"
KC_METRICS_ENABLED: "true"

Scrape configuration:

# prometheus.yml
scrape_configs:
  - job_name: keycloak
    metrics_path: /metrics
    static_configs:
      - targets: ['keycloak:9000']

Key Metrics to Monitor

Metric	Type	What It Tells You
`keycloak_user_events_total`	Counter	Login success/failure rates per realm
`http_server_requests_seconds_bucket`	Histogram	Request latency distribution
`agroal_active_count`	Gauge	Active DB connections (should match pool size under load)
`vendor_cluster_size`	Gauge	Number of nodes in cluster (should match expected count)
`jvm_memory_usage_after_gc_percent`	Gauge	Heap pressure (alert if consistently >85%)

Grafana Dashboards

Keycloak provides official dashboards at keycloak/keycloak-grafana-dashboard:

Troubleshooting Dashboard: SLI monitoring and deployment issues
Capacity Planning Dashboard: Password validations, login counts, load indicators

Community dashboards on Grafana.com: ID 10441 and 17878.

Troubleshooting

“Failed to initialize Liquibase”

Cause: Keycloak starts before PostgreSQL accepts connections.

Fix: Use depends_on with health check condition:

keycloak:
  depends_on:
    postgres:
      condition: service_healthy

Token Issuer Mismatch / Hostname Errors

Cause: KC_HOSTNAME doesn’t match the URL clients see, or proxy headers aren’t being forwarded.

Fix: Set KC_HOSTNAME to the full external URL including scheme:

KC_HOSTNAME=https://auth.example.com
KC_PROXY_HEADERS=xforwarded

Debug with KC_HOSTNAME_DEBUG=true, then check /realms/master/hostname-debug.

OOM Kills / High Memory Usage

Cause: Default MaxRAMPercentage=70 leaves insufficient room for non-heap memory.

Fix: Set container memory to minimum 2 GB and tune heap:

JAVA_OPTS_KC_HEAP: "-XX:MaxRAMPercentage=65 -XX:InitialRAMPercentage=50"

Slow Startup (30+ seconds)

Cause: Build phase runs on every container start.

Fix: Use the optimized Dockerfile from the Build Optimization section. Startup drops to under 10 seconds.

Cluster Nodes Not Discovering Each Other

Cause: Docker network blocks JGroups ports or IPv6 interferes with discovery.

Fix:

Ensure nodes share the same Docker network
Add JAVA_OPTS_APPEND: "-Djava.net.preferIPv4Stack=true"
Verify with docker compose logs | grep "ISPN000094"

For more Keycloak troubleshooting, see our Keycloak Session Expired Errors and Keycloak LDAP Connection Troubleshooting guides.

Keycloak Docker Compose Production: Complete Deployment Guide for 2026

Single-Node Production Setup

Docker Compose

Environment File

Key Configuration Decisions

Optimized Build for Faster Startup

Reverse Proxy Configuration

Nginx

Traefik (Docker Labels)

Caddy (Automatic TLS)

PostgreSQL Tuning

Automated Backups

Multi-Node Clustering

Clustered Docker Compose

Clustering Key Points

Security Hardening

Disable Unused Features

Separate Admin Hostname

Credential Management

Load Shedding

Monitoring

Prometheus Integration

Key Metrics to Monitor

Grafana Dashboards

Troubleshooting

“Failed to initialize Liquibase”

Token Issuer Mismatch / Hostname Errors

OOM Kills / High Memory Usage

Slow Startup (30+ seconds)

Cluster Nodes Not Discovering Each Other

Written by IAMDevBox

Latest Articles

Single-Node Production Setup#

Docker Compose#

Environment File#

Key Configuration Decisions#

Optimized Build for Faster Startup#

Reverse Proxy Configuration#

Nginx#

Traefik (Docker Labels)#

Caddy (Automatic TLS)#

PostgreSQL Tuning#

Automated Backups#

Multi-Node Clustering#

Clustered Docker Compose#

Clustering Key Points#

Security Hardening#

Disable Unused Features#

Separate Admin Hostname#

Credential Management#

Load Shedding#

Monitoring#

Prometheus Integration#

Key Metrics to Monitor#

Grafana Dashboards#

Troubleshooting#

“Failed to initialize Liquibase”#

Token Issuer Mismatch / Hostname Errors#

OOM Kills / High Memory Usage#

Slow Startup (30+ seconds)#

Cluster Nodes Not Discovering Each Other#

Related Articles#

Written by IAMDevBox

Related Articles

Latest Articles

Single-Node Production Setup

Docker Compose

Environment File

Key Configuration Decisions

Optimized Build for Faster Startup

Reverse Proxy Configuration

Nginx

Traefik (Docker Labels)

Caddy (Automatic TLS)

PostgreSQL Tuning

Automated Backups

Multi-Node Clustering

Clustered Docker Compose

Clustering Key Points

Security Hardening

Disable Unused Features

Separate Admin Hostname

Credential Management

Load Shedding

Monitoring

Prometheus Integration

Key Metrics to Monitor

Grafana Dashboards

Troubleshooting

“Failed to initialize Liquibase”

Token Issuer Mismatch / Hostname Errors

OOM Kills / High Memory Usage

Slow Startup (30+ seconds)

Cluster Nodes Not Discovering Each Other

Related Articles
