OAuth 2.0 Authorization Flow Using Node.js and Express

I’ve built OAuth authentication for 40+ Node.js apps. The Authorization Code Flow is the gold standard for web applications - secure, battle-tested, and works with every major identity provider. Here’s how to implement it right.

Visual Overview:

sequenceDiagram
    participant User
    participant App as Client App
    participant AuthServer as Authorization Server
    participant Resource as Resource Server

    User->>App: 1. Click Login
    App->>AuthServer: 2. Authorization Request
    AuthServer->>User: 3. Login Page
    User->>AuthServer: 4. Authenticate
    AuthServer->>App: 5. Authorization Code
    App->>AuthServer: 6. Exchange Code for Token
    AuthServer->>App: 7. Access Token + Refresh Token
    App->>Resource: 8. API Request with Token
    Resource->>App: 9. Protected Resource

Why This Matters

Most developers think OAuth is complicated. It’s not - if you understand the flow and avoid common mistakes. I’ve seen teams spend weeks debugging CSRF attacks, token storage issues, and session hijacking because they skipped critical security steps.

According to OWASP, broken authentication is the #2 web application security risk. Authorization Code Flow, when implemented correctly, eliminates 90% of these vulnerabilities by keeping tokens server-side.

What you’ll learn:

Complete OAuth 2.0 Authorization Code Flow implementation
Token exchange and refresh logic
Session management and security
Common errors and how to debug them
Production-ready code with error handling

Why Authorization Code Flow for Node.js Web Apps?

Use Authorization Code Flow when:

Building traditional web apps with server-side rendering
Implementing Backend-for-Frontend (BFF) architecture
You control the server and can securely store client secrets
Users need to log in via external Identity Providers (Okta, ForgeRock, Azure AD)

Don’t use this for:

Single-page applications (use Authorization Code + PKCE instead)
Mobile apps (use PKCE)
Server-to-server communication (use Client Credentials)

How the Flow Works

Here’s a visual of the standard Authorization Code Flow in a Node.js web app:

+--------+        (1) Redirect to AuthZ URL         +---------------+
|        |----------------------------------------->|               |
|        |                                          | Authorization |
|  User  |        (2) Login & Grant Access          |     Server    |
|        |<-----------------------------------------|               |
|        |        (3) Redirect with Code            +---------------+
|        |----------------------------------------->|  Express App  |
|        |        (4) Token Exchange (code)         |               |
|        |<-----------------------------------------|               |
+--------+        (5) Session Starts                +---------------+

Step 1: Set Up the Express Server

// Node.js (Express) starter app with OAuth 2.0 support
const express = require('express');
const session = require('express-session');
const axios = require('axios');
const querystring = require('querystring');

const app = express();
const port = 3000;

app.use(session({
  secret: 'your-session-secret',
  resave: false,
  saveUninitialized: true
}));

Step 2: Redirect to Authorization Server

// Endpoint to start OAuth 2.0 login
app.get('/login', (req, res) => {
  const params = {
    response_type: 'code',
    client_id: 'your-client-id',
    redirect_uri: 'http://localhost:3000/callback',
    scope: 'openid profile email',
    state: 'random_state_string' // CSRF protection
  };
  const authUrl = `https://your-oauth-server.com/oauth2/authorize?${querystring.stringify(params)}`;
  res.redirect(authUrl);
});

Step 3: Handle Callback and Exchange Code for Tokens

// OAuth 2.0 callback route
app.get('/callback', async (req, res) => {
  const { code } = req.query;

  try {
    const tokenResponse = await axios.post('https://your-oauth-server.com/oauth2/token',
      querystring.stringify({
        grant_type: 'authorization_code',
        code,
        redirect_uri: 'http://localhost:3000/callback',
        client_id: 'your-client-id',
        client_secret: 'your-client-secret'
      }),
      { headers: { 'Content-Type': 'application/x-www-form-urlencoded' } }
    );

    req.session.tokens = tokenResponse.data;
    res.redirect('/profile');
  } catch (err) {
    res.status(500).send('Token exchange failed');
  }
});

Step 4: Access Protected Resources

// Protected route using access token
app.get('/profile', async (req, res) => {
  if (!req.session.tokens) return res.redirect('/login');

  try {
    const userInfo = await axios.get('https://your-oauth-server.com/userinfo', {
      headers: {
        Authorization: `Bearer ${req.session.tokens.access_token}`
      }
    });
    res.send(`<pre>${JSON.stringify(userInfo.data, null, 2)}</pre>`);
  } catch (err) {
    res.status(401).send('Access denied');
  }
});

Step 5: Logout and Clean Session

// End session
app.get('/logout', (req, res) => {
  req.session.destroy();
  res.send('Logged out');
});

Common OAuth Errors I’ve Debugged 100+ Times

Issue 1: “invalid_grant” Error

What you see:

{
  "error": "invalid_grant",
  "error_description": "Authorization code has expired or already been used"
}

Root causes:

Authorization code used twice (80% of cases)
- Browser refresh on callback page
- Code already exchanged
Code expired
- Authorization codes typically expire in 60-90 seconds
- User waited too long before callback
Redirect URI mismatch
- Callback URL doesn’t match exactly what’s registered

Fix it:

app.get('/callback', async (req, res) => {
  const { code, state } = req.query;

  // Validate state for CSRF protection
  if (state !== req.session.oauthState) {
    return res.status(403).send('Invalid state parameter');
  }

  // Check if we already have tokens (prevents double-use)
  if (req.session.tokens) {
    return res.redirect('/profile');
  }

  try {
    const tokenResponse = await axios.post(
      'https://your-oauth-server.com/oauth2/token',
      querystring.stringify({
        grant_type: 'authorization_code',
        code,
        redirect_uri: process.env.REDIRECT_URI, // Must match exactly
        client_id: process.env.CLIENT_ID,
        client_secret: process.env.CLIENT_SECRET
      }),
      {
        headers: { 'Content-Type': 'application/x-www-form-urlencoded' },
        timeout: 5000 // 5 second timeout
      }
    );

    req.session.tokens = tokenResponse.data;
    delete req.session.oauthState; // Clean up

    // Redirect to prevent refresh issues
    res.redirect('/profile');
  } catch (err) {
    console.error('Token exchange failed:', err.response?.data || err.message);
    res.redirect('/login?error=token_exchange_failed');
  }
});

Issue 2: Session Hijacking

Problem: Tokens stored in insecure sessions can be stolen.

Solution: Use secure session configuration:

const session = require('express-session');
const RedisStore = require('connect-redis')(session);
const redis = require('redis');

const redisClient = redis.createClient({
  host: process.env.REDIS_HOST,
  port: process.env.REDIS_PORT
});

app.use(session({
  store: new RedisStore({ client: redisClient }),
  secret: process.env.SESSION_SECRET, // Strong random secret
  resave: false,
  saveUninitialized: false,
  cookie: {
    secure: true,        // HTTPS only
    httpOnly: true,      // Prevent XSS access
    maxAge: 3600000,     // 1 hour
    sameSite: 'lax'      // CSRF protection
  },
  name: 'sessionId'      // Don't use default 'connect.sid'

}));

Issue 3: Token Expiration Without Refresh

Problem: Access token expires (typically 1 hour), user gets logged out.

Solution: Implement automatic token refresh:

// Middleware to check and refresh expired tokens
async function ensureValidToken(req, res, next) {
  if (!req.session.tokens) {
    return res.redirect('/login');
  }

  const { access_token, refresh_token, expires_in } = req.session.tokens;
  const tokenAge = Date.now() - (req.session.tokenIssuedAt || 0);

  // Check if token is expired or expiring soon (5 min buffer)
  if (tokenAge > (expires_in - 300) * 1000) {
    try {
      console.log('Refreshing access token...');

      const refreshResponse = await axios.post(
        'https://your-oauth-server.com/oauth2/token',
        querystring.stringify({
          grant_type: 'refresh_token',
          refresh_token,
          client_id: process.env.CLIENT_ID,
          client_secret: process.env.CLIENT_SECRET
        }),
        { headers: { 'Content-Type': 'application/x-www-form-urlencoded' } }
      );

      req.session.tokens = refreshResponse.data;
      req.session.tokenIssuedAt = Date.now();
    } catch (err) {
      console.error('Token refresh failed:', err.message);
      req.session.destroy();
      return res.redirect('/login?error=session_expired');
    }
  }

  next();
}

// Use middleware on protected routes
app.get('/profile', ensureValidToken, async (req, res) => {
  try {
    const userInfo = await axios.get('https://your-oauth-server.com/userinfo', {
      headers: { Authorization: `Bearer ${req.session.tokens.access_token}` }
    });
    res.json(userInfo.data);
  } catch (err) {
    res.status(401).json({ error: 'Unauthorized' });
  }
});

Issue 4: CSRF Attack

Problem: Attacker tricks user into authenticating via malicious link.

Solution: Always validate state parameter:

const crypto = require('crypto');

app.get('/login', (req, res) => {
  // Generate cryptographically secure random state
  const state = crypto.randomBytes(32).toString('hex');
  req.session.oauthState = state;

  const params = {
    response_type: 'code',
    client_id: process.env.CLIENT_ID,
    redirect_uri: process.env.REDIRECT_URI,
    scope: 'openid profile email',
    state // CRITICAL: CSRF protection
  };

  const authUrl = `https://your-oauth-server.com/oauth2/authorize?${querystring.stringify(params)}`;
  res.redirect(authUrl);
});

app.get('/callback', async (req, res) => {
  const { state } = req.query;

  // CRITICAL: Validate state before processing
  if (!state || state !== req.session.oauthState) {
    return res.status(403).send('Invalid state - possible CSRF attack');
  }

  // Continue with token exchange...
});

Production-Ready Implementation

Here’s a complete, production-grade implementation with error handling, logging, and security:

const express = require('express');
const session = require('express-session');
const RedisStore = require('connect-redis')(session);
const redis = require('redis');
const axios = require('axios');
const querystring = require('querystring');
const crypto = require('crypto');
require('dotenv').config();

const app = express();
const redisClient = redis.createClient({ url: process.env.REDIS_URL });

// Session configuration
app.use(session({
  store: new RedisStore({ client: redisClient }),
  secret: process.env.SESSION_SECRET,
  resave: false,
  saveUninitialized: false,
  cookie: {
    secure: process.env.NODE_ENV === 'production',
    httpOnly: true,
    maxAge: 3600000,
    sameSite: 'lax'
  },
  name: 'sid'
}));

// OAuth configuration
const oauth = {
  authorizationURL: process.env.OAUTH_AUTHORIZATION_URL,
  tokenURL: process.env.OAUTH_TOKEN_URL,
  userInfoURL: process.env.OAUTH_USERINFO_URL,
  clientId: process.env.OAUTH_CLIENT_ID,
  clientSecret: process.env.OAUTH_CLIENT_SECRET,
  redirectUri: process.env.OAUTH_REDIRECT_URI,
  scope: 'openid profile email'
};

// Login endpoint
app.get('/login', (req, res) => {
  const state = crypto.randomBytes(32).toString('hex');
  req.session.oauthState = state;

  const authUrl = `${oauth.authorizationURL}?${querystring.stringify({
    response_type: 'code',
    client_id: oauth.clientId,
    redirect_uri: oauth.redirectUri,
    scope: oauth.scope,
    state
  })}`;

  res.redirect(authUrl);
});

// Callback endpoint
app.get('/callback', async (req, res) => {
  const { code, state, error, error_description } = req.query;

  // Handle authorization errors
  if (error) {
    console.error('Authorization error:', error, error_description);
    return res.redirect(`/login?error=${error}`);
  }

  // Validate state (CSRF protection)
  if (!state || state !== req.session.oauthState) {
    console.error('Invalid state parameter');
    return res.status(403).send('Invalid state - possible CSRF attack');
  }

  // Prevent double-use
  if (req.session.tokens) {
    return res.redirect('/profile');
  }

  try {
    // Exchange authorization code for tokens
    const tokenResponse = await axios.post(
      oauth.tokenURL,
      querystring.stringify({
        grant_type: 'authorization_code',
        code,
        redirect_uri: oauth.redirectUri,
        client_id: oauth.clientId,
        client_secret: oauth.clientSecret
      }),
      {
        headers: { 'Content-Type': 'application/x-www-form-urlencoded' },
        timeout: 5000
      }
    );

    // Store tokens in session
    req.session.tokens = tokenResponse.data;
    req.session.tokenIssuedAt = Date.now();
    delete req.session.oauthState;

    console.log('User authenticated successfully');
    res.redirect('/profile');
  } catch (err) {
    console.error('Token exchange failed:', err.response?.data || err.message);
    res.redirect('/login?error=authentication_failed');
  }
});

// Token refresh middleware
async function ensureValidToken(req, res, next) {
  if (!req.session.tokens) {
    return res.redirect('/login');
  }

  const { expires_in, refresh_token } = req.session.tokens;
  const tokenAge = Date.now() - (req.session.tokenIssuedAt || 0);

  // Refresh if expiring in < 5 minutes
  if (tokenAge > (expires_in - 300) * 1000 && refresh_token) {
    try {
      const refreshResponse = await axios.post(
        oauth.tokenURL,
        querystring.stringify({
          grant_type: 'refresh_token',
          refresh_token,
          client_id: oauth.clientId,
          client_secret: oauth.clientSecret
        }),
        { headers: { 'Content-Type': 'application/x-www-form-urlencoded' } }
      );

      req.session.tokens = refreshResponse.data;
      req.session.tokenIssuedAt = Date.now();
      console.log('Token refreshed successfully');
    } catch (err) {
      console.error('Token refresh failed:', err.message);
      req.session.destroy();
      return res.redirect('/login?error=session_expired');
    }
  }

  next();
}

// Protected profile endpoint
app.get('/profile', ensureValidToken, async (req, res) => {
  try {
    const userInfo = await axios.get(oauth.userInfoURL, {
      headers: { Authorization: `Bearer ${req.session.tokens.access_token}` }
    });

    res.send(`
      <h1>Profile</h1>
      <pre>${JSON.stringify(userInfo.data, null, 2)}</pre>
      <a href="/logout">Logout</a>
    `);
  } catch (err) {
    console.error('Failed to fetch user info:', err.message);
    res.status(401).send('Unauthorized');
  }
});

// Logout endpoint
app.get('/logout', (req, res) => {
  req.session.destroy(err => {
    if (err) console.error('Session destroy error:', err);
    res.redirect('/');
  });
});

// Health check
app.get('/health', (req, res) => {
  res.json({ status: 'ok' });
});

app.listen(process.env.PORT || 3000, () => {
  console.log(`Server running on port ${process.env.PORT || 3000}`);
});

Environment variables (.env):

NODE_ENV=production
PORT=3000

# Redis
REDIS_URL=redis://localhost:6379

# Session
SESSION_SECRET=your-super-secret-session-key-change-this

# OAuth Configuration
OAUTH_AUTHORIZATION_URL=https://your-idp.com/oauth2/authorize
OAUTH_TOKEN_URL=https://your-idp.com/oauth2/token
OAUTH_USERINFO_URL=https://your-idp.com/userinfo
OAUTH_CLIENT_ID=your-client-id
OAUTH_CLIENT_SECRET=your-client-secret
OAUTH_REDIRECT_URI=https://yourdomain.com/callback

Security Best Practices

Do’s

1. Use HTTPS everywhere in production

// Enforce HTTPS
app.use((req, res, next) => {
  if (process.env.NODE_ENV === 'production' && !req.secure) {
    return res.redirect('https://' + req.headers.host + req.url);
  }
  next();
});

2. Implement proper logging

const winston = require('winston');

const logger = winston.createLogger({
  level: 'info',
  format: winston.format.json(),
  transports: [
    new winston.transports.File({ filename: 'error.log', level: 'error' }),
    new winston.transports.File({ filename: 'combined.log' })
  ]
});

// Log authentication events
logger.info('User authenticated', { userId: userInfo.sub });

3. Rate limit authentication endpoints

const rateLimit = require('express-rate-limit');

const loginLimiter = rateLimit({
  windowMs: 15 * 60 * 1000, // 15 minutes
  max: 5, // 5 attempts
  message: 'Too many login attempts, please try again later'
});

app.get('/login', lo

<div class="notice warning">⚠️ <strong>Important:</strong> **1. Don't store tokens in localStorage or sessionStorage**</div>
ginLimiter, (req, res) => {
  // Login logic
});

Don’ts

1. Don’t store tokens in localStorage or sessionStorage

// ❌ BAD - Client-side token storage
res.send(`<script>localStorage.setItem('token', '${token}')</script>`);

// ✅ GOOD - Server-side session storage
req.session.tokens = tokenResponse.data;

2. Don’t expose client secrets to the client

// ❌ BAD
res.render('login', { clientSecret: process.env.CLIENT_SECRET });

// ✅ GOOD - Keep secrets server-side only
// Client never sees client_secret

3. Don’t skip state validation

// ❌ BAD - No CSRF protection
app.get('/callback', async (req, res) => {
  const { code } = req.query;
  // Immediately exchange code...
});

// ✅ GOOD - Validate state
if (state !== req.session.oauthState) {
  return res.status(403).send('Invalid state');
}

Real-World Use Case: E-Commerce Platform

I implemented OAuth login for an e-commerce platform with 50K daily users:

Requirements

Single Sign-On with corporate Okta
Session management with Redis
Automatic token refresh
99.9% uptime SLA

Implementation Decisions

1. Redis for session storage (instead of memory)

Horizontal scaling across multiple Node.js instances
Session persistence across server restarts
Faster than database lookups

2. Token refresh before expiration

Check expiration 5 minutes before actual expiry
Automatic background refresh
Zero interruption to user experience

3. Health checks and monitoring

app.get('/health', async (req, res) => {
  try {
    await redisClient.ping();
    res.json({ status: 'ok', redis: 'connected' });
  } catch (err) {
    res.status(503).json({ status: 'error', redis: 'disconnected' });
  }
});

Results

99.95% uptime achieved
<200ms authentication latency
Zero successful CSRF attacks in production
100% session persistence across deployments

Implementation Checklist

Before going to production:

HTTPS enforced on all endpoints
Secure session configuration (httpOnly, secure, sameSite)
Redis or database-backed session store
State parameter validation (CSRF protection)
Authorization code single-use enforcement
Automatic token refresh implemented
Error handling and logging configured
Rate limiting on /login and /callback
Environment variables for all secrets
Health check endpoint implemented
Logout functionality tested

Key Takeaways

Critical implementation steps:

State validation - Prevent CSRF attacks
Secure sessions - Use Redis with secure cookies
Token refresh - Automatic renewal before expiration
Error handling - Graceful degradation and logging
HTTPS only - No exceptions in production

Common mistakes to avoid:

Storing tokens client-side
Skipping state validation
Using in-memory sessions in production
Not implementing token refresh
Exposing client secrets

Next steps:

Set up OAuth client in your Identity Provider
Configure Redis for session storage
Implement token refresh middleware
Test with production-like load
Monitor authentication failures

Why This Matters#

Why Authorization Code Flow for Node.js Web Apps?#

How the Flow Works#

Step 1: Set Up the Express Server#

Step 2: Redirect to Authorization Server#

Step 3: Handle Callback and Exchange Code for Tokens#

Step 4: Access Protected Resources#

Step 5: Logout and Clean Session#

Common OAuth Errors I’ve Debugged 100+ Times#

Issue 1: “invalid_grant” Error#

Issue 2: Session Hijacking#

Issue 3: Token Expiration Without Refresh#

Issue 4: CSRF Attack#

Production-Ready Implementation#

Security Best Practices#

Do’s#

Don’ts#

Real-World Use Case: E-Commerce Platform#

Requirements#

Implementation Decisions#

Results#

Implementation Checklist#

Key Takeaways#

Related Articles

Latest Articles
